Style Guide

A reference of every markdown element and Nextra component available in this template. Use it as a cheat sheet when authoring pages.

Typography

Headings

# Heading 1
## Heading 2
### Heading 3
#### Heading 4
##### Heading 5
###### Heading 6

Headings 2–4 are automatically picked up by the table of contents on the right.

Paragraphs and inline formatting

A regular paragraph supports bold text, italic text, bold italic, strikethrough, inline code, and links to other pages or external URLs .

You can combine them: a bold link  or italic code.

Blockquotes

Documentation is a love letter that you write to your future self.

— Damian Conway

Nested blockquotes:

Outer quote.

Inner quote.

Horizontal rule

Lists

Unordered

• First item
• Second item
• Third item
  • Nested item
  • Another nested item
    • Deeply nested

Ordered

1. First step
2. Second step
3. Third step
   1. Sub-step
   2. Sub-step

Task list

• Completed task
• Another completed task
• Pending task
• Future task

Tables

Column alignment:

Images

Place images in /public and reference them with a root-relative path. Nextra optimizes them automatically:

For finer control, use the Next.js <Image> component (see CLAUDE.md for details).

Code

Inline code

Use backticks for inline code references like npm install, file names like next.config.mjs, or short snippets.

Fenced code block

const greet = (name) => `Hello, ${name}!`
console.log(greet('world'))

With filename

export const greet = (name: string) => `Hello, ${name}!`

Line highlighting

const a = 1
const b = 2 // highlighted
const c = 3
const d = 4 // highlighted
const e = 5 // highlighted
const f = 6 // highlighted

Line numbers

function add(a: number, b: number) {
  return a + b
}

add(2, 3)

Word highlighting

import { useState } from 'react'

function Counter() {
  const [count, setCount] = useState(0)
  return <button onClick={() => setCount(count + 1)}>{count}</button>
}

Diff-style

- const old = 'value'
+ const next = 'value'

Shell

npm install nextra nextra-theme-docs

Math (LaTeX)

Inline math: $E = mc^2$ and $\sum_{i=1}^{n} i = \frac{n(n+1)}{2}$.

Block math:

Nextra components

Callout (custom)

The template ships a custom <Callout> component registered globally — no import needed.

<Callout type="warning">Caution the reader.</Callout>

Callout (Nextra built-in)

Nextra’s own callout is available as NextraCallout in this page (imported and aliased to avoid colliding with the custom one above).

import { Callout } from 'nextra/components'

<Callout type="info">Your content here.</Callout>

Steps

npm run dev

npm run build

Tabs

npm install nextra nextra-theme-docs

pnpm add nextra nextra-theme-docs

yarn add nextra nextra-theme-docs

bun add nextra nextra-theme-docs

Cards

Cards are navigation tiles — title + optional icon + optional arrow. Always use the self-closing form. Children render as an unpadded banner above the title bar (intended for full-bleed images, not description text), so don’t put paragraph content inside a card.

<Cards>
  <Cards.Card title="Overview" href="/" arrow />
  <Cards.Card title="Nextra docs" href="https://nextra.site" arrow />
</Cards>

FileTree

• src
  • app
    • layout.tsx
    • [[...slug]]
  • content
    • _meta.js
    • index.mdx
    • styleguide.mdx
  • mdx-components.tsx
• next.config.mjs
• package.json

Bleed

<Bleed> extends content past the page gutter — useful for wide diagrams, screenshots, or embedded media.

Use <Bleed full> to extend all the way to the viewport edges.

Mermaid diagrams

Fenced code blocks tagged mermaid are rendered as live diagrams.

```mermaid
graph LR
  A[MDX source] --> B[remark-mermaid]
  B --> C[Mermaid component]
  C --> D[Rendered diagram]
```

A sequence diagram:

Images & ImageZoom

All plain markdown images are now click-to-zoom by default — ![]() is wired through <ImageZoom> in src/mdx-components.tsx.

You can also use the component explicitly if you need to pass next/image-specific props:

import { ImageZoom } from 'nextra/components'

<ImageZoom src="/toolbar.png" alt="…" width={1200} height={300} />

YouTube

<YouTube> embeds a privacy-enhanced (youtube-nocookie.com) player at a 16:9 aspect ratio.

<YouTube id="dQw4w9WgXcQ" title="Optional title" />
<YouTube id="..." start={120} />
<YouTube id="..." aspectRatio={[4, 3]} />

Video

<Video> wraps the native HTML5 <video> element with sensible defaults (controls, preload="metadata", playsInline).

<Video src="/clips/intro.mp4" poster="/clips/intro-poster.jpg" />

{/* Multi-format fallback */}
<Video
  src={[
    { src: '/clips/intro.webm', type: 'video/webm' },
    { src: '/clips/intro.mp4',  type: 'video/mp4'  }
  ]}
/>

Drop video files under /public and reference them with root-relative paths, same as images.

Embed

<Embed url="..."> is a one-stop wrapper for arbitrary URLs. Known providers render as a rich iframe; unknown URLs fall back to a simple link card.

Currently routed providers: YouTube, Vimeo, Loom, CodePen, Figma.

Unknown URL → link card fallback:

<Embed url="https://www.youtube.com/watch?v=..." />
<Embed url="https://vimeo.com/123456789" />
<Embed url="https://www.loom.com/share/abc..." />
<Embed url="https://codepen.io/user/pen/xyz..." />
<Embed url="https://www.figma.com/file/abc.../Title" />

Prefer the dedicated <YouTube> / <Video> components when you know the source — they’re slightly more configurable. Use <Embed> when the source could vary or when you want consistent “any-URL-works” behavior in authored content.

Button

<Button> is a styled action button with default and outline variants. It’s a thin wrapper around Headless UI’s button.

'use client'
import { Button } from 'nextra/components'

export function ButtonDemo() {
  return (
    <>
      <Button onClick={() => alert('clicked')}>Default button</Button>
      <Button variant="outline" onClick={() => alert('clicked')}>
        Outline button
      </Button>
    </>
  )
}

Note: event handlers like onClick are functions and can’t be passed from a server-rendered MDX file directly to a client component. Wrap interactive buttons in a 'use client' component (as above) and import that into MDX.

Collapse

<Collapse> is a controlled show/hide region with height + opacity animation. You drive isOpen from your own state.

'use client'
import { useState } from 'react'
import { Collapse, Button } from 'nextra/components'

export function CollapseDemo() {
  const [isOpen, setIsOpen] = useState(false)
  return (
    <>
      <Button variant="outline" onClick={() => setIsOpen(o => !o)}>
        {isOpen ? 'Hide' : 'Show'}
      </Button>
      <Collapse isOpen={isOpen}>{/* … */}</Collapse>
    </>
  )
}

For collapsible content that should be visible to search engines, prefer the native <details> / <summary> HTML elements.

Popup

<Popup> is a hover-triggered popover. Useful for inline definitions and footnote-style asides.

Hover the underlined term for a definition:

import { Popup } from 'nextra/components'

<Popup>
  <Popup.Button as="span">trigger text</Popup.Button>
  <Popup.Panel>panel content</Popup.Panel>
</Popup>

Select

<Select> is a styled controlled <select>-like dropdown. Most often used for compact in-page filters or option pickers (theme, version, language).

'use client'
import { useState } from 'react'
import { Select } from 'nextra/components'

const options = [
  { id: 'system', name: 'System' },
  { id: 'light',  name: 'Light' },
  { id: 'dark',   name: 'Dark' }
]

const [value, setValue] = useState('system')

<Select
  value={value}
  onChange={setValue}
  options={options}
  selectedOption={<span>Theme: {value}</span>}
/>

Playground

<Playground> compiles a string of MDX in the browser and renders it inline. Useful for live API demos or component examples where you want readers to see source + output side by side without a separate sandbox.

import { Playground } from 'nextra/components'
import { useMDXComponents } from '../mdx-components'

<Playground
  source={`
## Hello from Playground

This MDX is compiled at runtime.
  `}
  components={useMDXComponents()}
  fallback={<p>Loading…</p>}
/>

Note: Playground pulls the MDX compiler into the client bundle on first render, so use sparingly — not on every page.

Banner

<Banner> is a site-wide announcement strip rendered above the navbar. It’s wired in src/app/layout.tsx, not used inline in MDX.

import { Banner, Layout, Navbar, Footer } from 'nextra-theme-docs'

const banner = (
  <Banner storageKey="release-1.0">
    🎉 v1.0 is out — <a href="/release-notes">read the notes</a>
  </Banner>
)

<Layout banner={banner} navbar={<Navbar … />} footer={<Footer …/>} …>
  {children}
</Layout>

storageKey lets the banner remember it’s been dismissed per visitor.

Rich tables (DataTable)

GFM |-syntax tables can hold one line of plain text per cell. When you need multi-paragraph cells, lists, callouts, or other components inside cells, use <DataTable> instead.

Column alignment:

<DataTable
  headers={['Column A', 'Column B']}
  widths={['30%', '70%']}
  align={['left', 'right']}
  caption="Optional caption rendered above the table."
>
  <DataTable.Row>
    <DataTable.Cell>Cell content</DataTable.Cell>
    <DataTable.Cell>
      Can contain **markdown**, components, lists — anything MDX allows.
    </DataTable.Cell>
  </DataTable.Row>
</DataTable>

API:

• headers={[...]} — optional column headers (omit for headerless tables)
• align={['left' | 'center' | 'right', ...]} — per-column alignment, applied to both header and body cells
• widths={['20%', '160px', 'auto', ...]} — per-column width
• caption={...} — optional caption above the table
• <DataTable.Row> — wraps a row
• <DataTable.Cell> — a body cell; supports colSpan, rowSpan, per-cell align override
• <DataTable.HeaderCell> — for inline header cells if you don’t use the headers prop

DataTable is registered globally in src/mdx-components.tsx — no import needed in MDX.

Sidebar grouping (_meta.js)

Long sidebars get unwieldy without section headers. Add a separator with a title between groups:

export default {
  index: { title: 'Overview', theme: { breadcrumb: false } },

  'core': { type: 'separator', title: 'Core' },
  concepts: 'Concepts',
  architecture: 'Architecture',

  'reference': { type: 'separator', title: 'Reference' },
  styleguide: 'Style Guide'
}

The key ('core', 'reference') is arbitrary — only type and title matter. With title: bold, slightly elevated header text. Without title: a plain <hr>. Group headers can appear at any depth (top-level _meta.js or any nested section’s _meta.js).

The custom PageBreadcrumb (in src/components/PageBreadcrumb.tsx) reads the same _meta.js and prepends the active group as the leading crumb when present.

Frontmatter

Each page may declare a title and description in YAML frontmatter. These feed the <title> tag and meta description.

---
title: My Page
description: One-sentence summary used for SEO and previews.
---

# My Page

Content here…

Sidebar configuration (_meta.js)

Control sidebar order, titles, and per-page theme options:

export default {
  index: {
    title: 'Overview',
    theme: { breadcrumb: false }
  },
  styleguide: 'Style Guide'
}
